Type-C PD/QC/AFC Fast Charge Decoy Trigger Support 5V 9V 12V 15V 20V Fixed Voltage Output

A decoy voltage module (or PD/QC decoy/trigger) is a small, specialized circuit board that negotiates with USB-C PD (Power Delivery) or QC (Quick Charge) power supplies to output a specific, fixed voltage (e.g., 5V, 9V, 12V, 15V, 20V) instead of the default 5V. It tricks chargers into providing higher voltages.

The Type-C QC AFC PD2.0/PD3.0 to DC Fast Charge Trigger Detector Module is a versatile device designed to convert and regulate power from USB Type-C ports to a stable DC output. This module supports multiple fast-charging protocols, including QC (Quick Charge), AFC (Adaptive Fast Charging), and PD (Power Delivery), making it compatible with a wide range of devices. It allows users to seamlessly adapt USB-PD notebook chargers or power banks for powering various DC devices, offering convenience and efficiency in one compact design.

Applications:

1. This module is perfect for DIY enthusiasts, engineers, and anyone looking to utilize fast-charging USB Type-C devices for DC-powered systems.
2. Convert USB Type-C power adapters to DC voltage for custom electronics.
3. Test and simulate fast-charging protocols for device development.
4. Power notebook peripherals, IoT devices, or microcontrollers.
5. Integrate into DIY battery charging or power conversion setups.
6. Debug and monitor USB fast-charging devices.

Notice:
1. After adjusting the DIP switch, because there is no voltage indicator, it is recommended to use a multimeter to measure the voltage before connecting to the application circuit.
2. If the DIP switch is not adjusted according to the table, the module will output any one of the above voltages.

Features:

• Fast Charge Compatibility: Supports QC 2.0/3.0, AFC, and PD2.0/PD3.0 protocols, ensuring quick and reliable charging.
• Wide Application: Converts USB Type-C power input to DC output, suitable for DIY projects, electronics, and powering small devices.
• Voltage and Current Triggering: Offers precise control to trigger specific voltages and currents for safe and efficient charging.
• Compact Design: Small and lightweight, easy to integrate into various setups or carry for on-the-go use.
• Stable Output: Ensures consistent DC power delivery, protecting devices from overvoltage and overcurrent.
• LED Indicators: Equipped with indicator lights to display working status and protocol compatibility.
• High Compatibility: Works with USB-C power banks, PD notebook adapters, and other compatible chargers.
• Durable Build: Made from high-quality materials for reliable and long-lasting performance.
• Easy to Use: Plug-and-play design allows users to quickly adapt the module for their specific requirements.
• Adjustable Output: Some models offer customizable output voltage ranges to fit diverse applications.
