▼ Modulation: Analog
Torque:
4.8V: 44.0 oz-in (3.17 kg-cm)
6.0V: 57.0 oz-in (4.10 kg-cm)

▼ Speed:
4.8V: 0.23 sec/60°
6.0V: 0.19 sec/60°

▼ Weight:
1.31 oz (37.0 g)

▼ Dimensions:
Length: 1.57 in (39.9 mm)
Width: 0.79 in (20.1 mm)
Height: 1.42 in (36.1 mm)

▼ Operating voltage: 4.8-6V
Temperature rang: 0℃_ 55℃
Dead band width: 5us
Gear Type: Plastic
Rotation/Support: Bushing


▼ The wire colors are:
Red = Battery(+)
Black = Battery(-)
White = Signal
