▼ Features
Wide working input voltage from DC 5 to 36V, widely used in many device
Interface are clear and simple, and meet all your needs
Emergency "STOP" button
Reverse polarity protection, reverse polarity will not burn this module board
Sleep Mode - Enabled, screen will automatically turn off if without any operation for 5 minutes, any key will wake it up
Settable OP, CL, LOP, which are independent of each other and are automatically saved
After the module is powered down, all settings are memorized and will not lost
Optocoupler isolation, enhanced anti-jamming capability, industrial grade board
Operation time adjustable from 0.1 second to 999 minutes

▼ Specifications
Power Supply: 6 - 12V DC / Micro USB 5.0V DC
Trigger Source: Active-high (3.0 - 12V)
Output capability: DC 30VDC 5A or 220VAC 5A device
Standby Current: 20mA
Operating Current: 50mA
Life span: more than 10 million times
Working temperature: -40 to +85 ℃
Size: 6.2 * 3.8 * 1.7cm

▼ Package Included
1 x Timer board
1 x User manual

▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖▖
